Kampuočiai karštojo valcavimo lygus kampas
Warunki techniczne wykonania według:
PN-91/H-93010,
DIN EN 10025 1991
Wymiary: 20×20 do 200×200 mm
Wg: PN-EN
10056-1:2000,
PN-EN 10056-2:1998,
DIN 1028 1994
Techniniai duomenys
| Wyróżnik
oznaczenia |
Wymiary | Pow.
przekr. |
Masa
1m |
|||
| a | g | Rmax | Rlmax | |||
| [mm] | [cm2] | [kg] | ||||
| 40x40x4 | 40 | 4 | 6 | 3 | 3,08 | 2,42 |
| 40x40x5 | 40 | 5 | 3 | 3,79 | 2,97 | |
| 45x45x4 | 45 | 4 | 7 | 3,5 | 3,49 | 2,74 |
| 45x45x5 | 45 | 5 | 3,5 | 4,3 | 3,38 | |
| 50x50x4 | 50 | 4 | 7 | 3,5 | 3,89 | 3,06 |
| 50x50x5 | 50 | 5 | 4,8 | 3,77 | ||
| 50x50x6 | 50 | 6 | 5,69 | 4,47 | ||
| 60x60x5 | 60 | 5 | 8 | 4 | 5,82 | 4,57 |
| 60x60x6 | 60 | 6 | 6,91 | 5,42 | ||
| 60x60x8 | 60 | 8 | 9,03 | 7,09 | ||
| 75x75x6 | 75 | 6 | 9 | 4,5 | 8,73 | 6,85 |
| 75x75x7 | 75 | 7 | 10,1 | 7,94 | ||
| 75x75x8 | 75 | 8 | 11,5 | 9,03 | ||
| 80x80x6 | 80 | 6 | 10 | 5 | 9,35 | 7,34 |
| 80x80x8 | 80 | 8 | 12,3 | 9,66 | ||
| 80x80x10 | 80 | 10 | 15,1 | 11,9 | ||
| 90x90x6 | 90 | 6 | 11 | 5,5 | - | 8,3 |
| 90x90x7 | 90 | 7 | - | 9,61 | ||
| 90x90x8 | 90 | 8 | - | 10,9 | ||
| 90x90x9 | 90 | 9 | - | 12,18 | ||
| 90x90x10 | 90 | 10 | - | 13,45 | ||
| 90x90x11 | 90 | 11 | - | 14,7 | ||
| 100x100x8 | 100 | 8 | 12 | 6 | - | 12,18 |
| 100x100x10 | 100 | 10 | - | 15,05 | ||
| 100x100x12 | 100 | 12 | - | 17,83 | ||
| 120x120x10 | 120 | 10 | 13 | 6,5 | - | 18,2 |
| 120x120x12 | 120 | 12 | - | 21,62 | ||
| 130x130x12 | 130 | 12 | 16 | 8 | 30 | 23,6 |
| 150x150x8 | 150 | 8 | 16 | 6,5 | 22,94 | 18 |
| 150x150x10 | 150 | 10 | 28,68 | 22,5 | ||
| 150x150x12 | 150 | 12 | 8 | 34,8 | 27,3 | |
| 150x150x15 | 150 | 15 | 43 | 33,8 | ||
| 160x160x12 | 160 | 12 | 16 | 8 | 37,2 | 29,2 |
| 160x160x15 | 160 | 15 | 46,1 | 36,2 | ||
| 180x180x16 | 180 | 16 | 18 | 9 | 55,4 | 43,5 |
| 180x180x18 | 180 | 18 | 61,9 | 48,6 | ||
